Mechanical Parameters

• Cell Type: N-type Monocrystalline Silicon Cells

• Number of Cells: 144 (72 × 2, half-cut cells)

• Module Dimensions: 2278 × 1134 × 30 mm

• Module Weight: 27.0 kg

• Front Glass: 3.2 mm high-transmittance coated tempered glass, optional low-iron tempered glass, or embossed tempered glass

• Frame: Anodized Aluminum Alloy

• Junction Box: IP68 Protection Grade

• Safety Class: Class II

• Fire Rating: Class C

• Connector Type: JK03M / MC4 / Others

• Cable Cross-section: 4.0 mm²

• Cable Length: (+): 300 mm, (−): 200 mm; customizable upon request
